11.4 Installing the rear push bar (only for CM900-xx)
Raise the rear bar positioned behind the backrest (fig.13). Slide the end of the support tube
into the attachment and insert the pin with relative iron. (fig.14)
t
(fig.13) Rear support bar (fig.14) Pin with iron
11.5 Adjusting comfort
Before starting to use your ARDEA MOBILITY electric wheelchair by Moretti, carry out all
the adjustments indicated below to obtain a comfortable driving and seating position suited
to the user.
1. Adjusting the armrest height
2. Tipping and extracting the armrests
3. Adjusting the controller position
4. Adjusting the height of the roll-over protection wheels
1. Adjusting the armrest height
The height of the armrests on your electric wheelchair is adjustable. To adjust the height,
pull the knob outwards (fig.15), slide the armrest until it reaches the desired height (fig.16),
then lock the armrest into the preferred position.
(fig.15) Knob (fig.16)
