PART 8: FIELD WIRING (CONTINUED)
mode and the other light will be on when the
boiler is in lockout mode.
E. LOW VOLTAGE CONNECTIONS FOR
STANDARD BOILER
1. All low voltage cables should enter the
electrical junction box through the provided
knock out holes as shown below.
2. Connect all low voltage field devices to the
low voltage terminal strip located in the
electrical junction box (shown in Figure 8-1).
