Mod 102 - Label Mounting Instructions

17
Label Mounting Instructions
FRONT
REAR
TOP
½”
11/16"
3/8" 3/8" 3/8" 3/8"
ON/OFF BASS TREBLE VOLUME
The labels are meant to be placed over their respective chassis holes indicated below. There are
four labels for the front panel and two labels for the rear panel.
Cutting the Circle
Each circle on the labels is sectioned into eight
pieces to help you cut out a nice circular shape
for placement over its respective chassis hole.
ON
OFF
ON
OFF
MOD 102
TUBE AMP KIT
BASSBASS
0
1
2
3
4
5
6
7
8
9
10
TM
modkitsdiy.com
VOLUMEVOLUME
0
1
2
3
4
5
6
7
8
9
10
TREBLETREBLE
0
1
2
3
4
5
6
7
8
9
10
ON
OFF
2) Then cut along the circumference, section
by section, removing one sectional piece at a
time.
1) Use a razor or x-acto knife to cut along
each line first.
Ω
3/8"
½”
3/8"
TOP
8 OHM
1 AMP FAST BLO
(FUSE)
