Mod Nexus Series - Page 12

Phase / Off
11
PCB BOMs
Input Jack
Output Jack
Ribbon Cable
Ground Wire
+9V Wire
1/4" Jack
1/4" Jack
4 Conductor
Black
Red
1/4" PCB Mount Jack
1/4" PCB Mount Jack
4 Conductor Flexstrip Ribbon
Pretinned 24AWG Wire
Pretinned 24AWG Wire
Jack PCB
SIDE 1 SIDE 2
Part Value
Type
✔
Switch PCB
SIDE 1 SIDE 2
RLED
LED
Footswitch
Ribbon Cable
1KΩ
Blue
3PDT
6 Conductor
1/8W Metal Film Resistor
5mm Diused LED
Low Prole 3PDT Footswitch
6 Conductor Flexstrip Ribbon
Part Value
Type
✔
