Main Topmast Stay - The top of the stay is
seiz
ed around the rigging stop on the main
topmast, passes thru an eyebolt on the fore-
mast cap and sets to an ey
ebolt on the
for
emast tr
estletr
ee (Figure G-12).
Main Topgallant Staysail Stay - Seize the
stay ar
ound the upper rigging stop of the
main topmast. The lower end is secured to an
eyebolt in the fore topmast head cross-tree
(Figure G-13).
Main Topgallant Stay - The upper end is
seized around the upper rigging stop of the
main topmast. The lower end is seized to a
bullsey
e and str
op ar
ound the for
e topgallant
mast lo
w
er rigging stop (F
igure G-14).
FIG. G-2 DEADEYE
