Model Shipways Newsboy - Hatches

9
FIG. D-4 CAVILS & PIN RAILS
FIG. D-6 FORWARD CABIN
FIG. D-8
HATCHES
FIG. D-7
AFT
COMPANIONWAY
& SKYLIGHT
FIG. D-5 CHANNELS
PIN OR
JUST GLUE
T
OP PLANKING
TOP
MOULDINGS
CORNER POST
CHAMFER EDGE
COAMING
COAMING
PAWL IS
ON
CASTING
RA
TCHET ON
WINDLASS
CASTING P/S
BITT
CASTING
WIRE
GLUE
ARMS
T
O RA
TCHET
MAKE CRANK FROM
WOOD OR METAL
CUT ARMS
FROM WOOD
OR MET
AL
CUT ARMS
FROM WOOD
OR MET
AL
HATCH UNITS
2 GROOVES
FOR CANVAS
COVER TIE
DOWN ROPES
SIMPLIFIED
HA
TCH COVER -
SCRIBE JOINTS
LASER CUT
SIDES & ENDS
LASER CUT BEAM,
2 - EQ
UALLY SPACED
SCRIBE PANEL
LINES ON DOOR
FIT PIN RAIL
UNDER
CAP RAIL
DRILL HOLES
FOR BELAYING PINS
CUT SLO
TS FOR
STANCHIONS
CAP RAIL
NO
TCH FOR
CHAINPLA
TE -
INSTALL
CHAINPLATES,
THEN ADD
CO
VER STRIP
CHANNEL
TYPICAL CAVIL
TYPICAL
PIN RAIL
MODEL
REAL SHIP
OPTION
WINDOW FRAME
& SLIDING PANEL
SLIDE RAILS
DOOR
FRAME
SCRIBE PANEL
LINES ON DOORS
CENTER HINGE
BEAM
BASE CO
AMING
HINGED
LIFT TOP
SLIDING
COVER
CAP
RAIL
SKYLIGHT
FIG. D-9
WINDLASS &
BOWSPRIT BITT
Plank, Mouldings,
windowframes,
coamings &
cor
ner posts
constr
ucted same
as forward cabin
COMPANIONWAY
