Modern Forms Wynd - Hanging the Fan Assembly

FR-W180112
Downrod
Clevis Pin
Cotter Pin
Screws (2)
Collar
Safety Cable
Motor Wires
65
1. Remove screw from hanger ball. Remove hanger ball and cross pin.
2. Loosen 2 screws, clevis pin and cotter pin.
1. Install coupling cover, canopy screw ring, canopy and downrod
assembly into motor housing as shown.
07
Hanging the Fan
