Modern Forms Wynd - Canopy and Motor Housing Setup

13FR-W1801
Motor Wires
Safety Cable
Canopy
Downrod
Coupling Cover
Canopy Screw Cover
7
Safety Cable
Wood Screw
8
Hanging the Fan
07
1. Align downrod and motor collar holes, re-insert pins and screws.
2. Slip up canopy and canopy screw cover. Re-install hanger ball
with cross pin in correct place.
1. Seat all into the mounting bracket. Rotate until ball drops and
locks into hanger bracket screw.
