17FR-W1801
Finishing the Installation
09
13
Screws
Outlet box
Hanger
Bracket
Canopy
Canopy Screw Cover
1. Secure wire connectors with supplied wire ties.
2. Install canopy to mounting bracket with the screw removed in
section 5.
3. Install canopy screw ring as shown.
