Modern Forms Wynd - Installing the Luminaire Module; Adapter Plate and LED Wire Connection

FR-W180118
Mounting Ring
Screw
Adapter Plate
14
10
Installing the Luminaire Module
1. Remove 1 of 3 screws and loosen the others (do not remove).
2. Using the screw from the previous step, install the adapter plate.
NOTE: If you are not installing the luminaire module skip to step 18.
1. Attach LED wires from motor assembly to luminaire module.
2. Install glass shade without over-tightening.
