Modine Manufacturing PTX - GENERAL PERFORMANCE DATA - MODELS PTX & BTX; PROPELLER UNIT MODEL PTX PERFORMANCE DATA; BLOWER UNIT MODEL BTX PERFORMANCE DATA

26
6-534.1
Table 26.1 - Propeller Unit Model PTX General Performance Data
Model PTX Sizes
150 175 200 250 300 350 400
Btu/Hr Input 
150,000 175,000 200,000 250,000 300,000 350,000 400,000
Btu/Hr Ouput 
123,000 143,500 166,000
m
207,500
m
249,000
m
290,500
m
332,000
Efficiency
82% 82% 83%
m
83%
m
83%
m
83%
m
83%
Entering Airflow (CFM)
@ 70°F
2140 2725 2870 3995 4545 5280 5995
Outlet Velocity (FPM)
711 607 643 721 824 748 851
Air Temp. Rise (°F)
53 48 52 47 50 50 51
Max. Mounting Height
(Ft.) 
15 14 15 18 19 18 21
Heat Throw (Ft.) @
Max Mtg Ht 
51 50 53 62 69 65 74
Motor Type 
PSC PSC PSC PSC PSC PSC PSC
Motor HP
1/6 1/6 1/3 1/3 1/2 1/2 3/4
Motor RPM
1075 1075 1075 1075 1075 1125 1125
 Ratings shown are for elevations up to 2,000'. For elevations above 2,000', ratings should be reduced at the rate of 4%
for each 1,000' above sea level (in Canada see rating plate.) Reduction of ratings requires use of a high altitude kit.
 Data taken at 55°F air temperature rise. At 65°F ambient and unit red at full-rated input. Mounting height as measured
from bottom of unit, and without deector hoods. For units equipped with deector hoods, see page 27.
 All motors used are produced, rated and tested by reputable manufacturers in accordance with NEMA standards and
carry the standard warranty of both the motor manufacturer and Modine. All motors are totally enclosed and all single
phase motors have built-in thermal overload protection.
m For models sizes 200,250,300, and 350 the efciency is 83% for 1 pipe vented installation and 82% for 2 pipe
separated combustion installation. Btu/Hr output shown is for 1 pipe vented installation, corresponding Btu/Hr output for
2 pipe separated combustion installation is 1 percentage point lower.
Table 26.2 - Blower Unit Model BTX General Performance Data
Model BTX Sizes
150 175 200 250 300 350 400
Btu/Hr Input 
150,000 175,000 200,000 250,000 300,000 350,000 400,000
Btu/Hr Output 
123,000 143,500 164,000 205,000 246,000 287,000 328,000
Efficiency 82% 82% 82% 82% 82% 82% 82%
Entering Airflow
Range (CFM)
1587-
2778
1852-
3241
2116-
3704
2646-
4630
3175-
5556
3704-
6481
4233-
7407
Outlet Velocity (FPM) 543-903 428-711 489-813 497-826 596-991 543-903
621-
1032
Air Temp. Rise (°F) 40-70 40-70 40-70 40-70 40-70 40-70 40-70
Max. Mounting Height
(Ft.) 
9-21 8-18 9-21 10-22 11-26 11-26 13-29
Heat Throw (Ft.) @
Max Mtg Ht 
33-75 28-65 32-74 34-78 40-94 39-90 44-102
Motor Type 
T.E T.E T.E T.E T.E T.E T.E
Motor HP See Table 21.1
Motor RPM 1725 1725 1725 1725 1725 1725 1725
GENERAL PERFORMANCE DATA - MODELS PTX & BTX
