INSTALLATION
6
7
STUDS
STANDARD
HEIGHT
-
84" FROM
FLOOR
7.1 Secure Rear Hanging Cleats (C) to
studs using 2.5" Screws (J). Tighten
Screws using Square Drill Bit (provided)
and Drill.
D
C
C
6.1
6.2
6.3
Determine the mounting location for the
unit.
Using a stud finder, locate studs to which
the unit will be secured. Mark stud
locations with a pencil.
With the unit positioned at the desired
location, level the unit, then drill pilot
holes through Rear Hanging Cleats (C),
PILOT HOLES
NOTE: For 18" and 24" units, it is likely that
only one stud will pass through the
unit. In these cases, use two screws
through each Rear Hanging Cleat.
ASSEMBLY AND
INSTALLATION INSTRUCTIONS
TALL HANGING UNIT
C
J
