Monitor Audio PL - Specifications; Owner Information

Specifications.
Frequency Response 52Hz - 100kHz
Sensitivity (1W@1m). dB 90
Nominal Impedance. ohms 4
Maximum SPL dBA (each) 117.8
Power Handling (RMS) watts 200
Recommended Amplifier Requirements 100 - 200
(RMS) watts
Bass Alignment Sealed Cabinet
System Design 3 - way
Mid - H.F Crossover Frequency (Hz) 2400
Bass Low Pass Crossover Frequency (Hz) 380
Drive Unit Complement 2 x 6.5” long-throw RDT
®
bass drivers
1 x 4” RDT
®
mid-range driver
1 x C-CAM
®
high frequency ribbon
transducer
Fixings 10 x Tri-grip dog leg type fixing system
Dimensions With Grille (H x W x D) 1205 x 330 x 116 mm
(47
7/16
x 13 x 4
9/16
Inches)
Dimensions Without Grille (H x W x D) 1205 x 330 x 102 mm
(47
7/16
x 13 x 4 Inches)
Cut out Depth 97.5 mm (3
13/16
inches)
Cut out Dimensions (H x W) 1179 x 302 mm (46
7/16
x 11
7/8
inches)
Weight 25 kg (55 lbs)
Owner Information
Product Details
Product Serial No ................................................
Date of Purchase ................................................
Dealer Details
Dealer Name .....................................................................................................................
Address .............................................................................................................................
...........................................................................................................................................
e-mail address ...................................................................................................................
Telephone Number ............................................................................................................
Monitor Audio reserves the right to alter specifications without notice.
For the 5 years manufacturer’s warranty and to be entered into our monthly prize draw, please visit the online
registration form at: www.monitoraudio.com
