Monitor Audio Silver 1 User Manual

Silver Series10
Connecting Speaker Cables
Bare Wire Connection
Unscrew the binding posts and pass
the bare wire through the through-hole
and tighten the binding post to clamp
the wire in place.
Banana Plugs
Remove the red and black plastic plugs
from the terminals and insert the banana
plugs into the holes that are revealed.
A knife blade of flat blade screwdriver
may be required to gain purchase on
the plugs.
Single Wire
Connect the banana plugs/ bare wire to
the terminals. Connect to either the top,
bottom or diagonally (experimentation
is advisable to achieve the preferred
results).
Leave the terminal links in
place.
Bi-Wire/ Bi-Amp
Connect the banana plugs/ bare wire to
the top and bottom terminals (positive
to positive and negative to negative).
The terminal links MUST be
removed.

Monitor Audio Silver 1 Specifications

General

Bass reflex	Yes
Product color	Black
Housing material	Wood
Recommended usage	Universal
Suitable for outdoor use	No
Woofer	-
Speaker type	2-way
Tweeter diameter	25 mm
Number of drivers	2
Speaker placement	Tabletop/bookshelf
Audio output channels	1.0 channels
Driver diaphragm material	Aluminum
Number of tweeter drivers	1
Tweeter diameter (imperial)	1 \
Mid-range driver diameter (imperial)	6 \
Recommended amplifier power (max)	100 W
Recommended amplifier power (min)	40 W
Impedance	8 Ω
Sensitivity	87 dB
Frequency range	45 - 35000 Hz
Crossover frequency	3000 Hz
Finish type	High-gloss
Connectivity technology	Wired

Weight and Dimensions

Depth	275 mm
Width	185 mm
Height	312 mm
Weight	6950 g
