3.Digital Mode operations
4.1 Receiving
Firstly, ensure your wire connection is all right 。 Turn on
power of digital modem（Press
B1+B2 for 1~2s
），If there is
FFT spectrum display. Congratulations, Receiving is OK。Easy
work,
(Some radio needs to turn OFF SQL)
Set the appropriate MODE(see Appendix
1.<Mode>),Then adjust the cursor to the peak, Decoding
message will shows。
Spectrum display Signal peak & Decoding text
4.2 Transmitting
First, please make sure Radio station is connected with
ANT or dummy load for TX。Then, Check the radio pwr meter
if there is any power output, after press Insert for
transmitting. If does, Nice work, Modem could output
normally.
