Installation and Operation Manual Eco Convection Ovens | 4/5/7/10-Tray | Steam
FG1BX-UK-MAN-0100 | Rev. A23 (March 2023) MONO
55
PART 2 4/5 Tray 18” x 30” Oven Spares Section
Oven Code FG159
Figure 18: Rear view with outer sheeting removed (FG159)
A. Motor and Element ....................... (Part 2 / Section 1 on Page 56)
B. Main Panel ................................... (Part 2 / Section 2 on Page 57
C. Damper ......................................... (Part 2 / Section 3 on Page 58)
D. Water System ............................... (Part 2 / Section 4 on Page 59)
E. Baking Chamber and Door Parts . (Part 2 / Section 5 on Page 61)
