63
PART 3 4/5 Tray 60cm x 40cm Oven Spares Section
Oven Code FG158
Figure 25: Rear view with outer sheeting removed (FG158)
A. Motor and Element ....................... (Part 3 / Section 1 on Page 64)
B. Main Panel ................................... (Part 3 / Section 2 on Page 65)
C. Damper and fan............................ (Part 3 / Section 3 on Page 66)
D. Water System ............................... (Part 3 / Section 4 on Page 67)
E. Baking Chamber and Door Parts . (Part 3 / Section 5 on Page 69)
