Monogram ZISB42DY - Side Panel or Filler Options

For All Monogram Built-In Refrigerators
Side Panel or Filler Options
(not to scale)
Side panels must be used whenever the sides of the refrigerator
will be exposed.
24 3/4"
84"
3 3/4"
Standard 4" high toekick or trim to fit.
Height may vary depending on application.
Standard 4" high toekick or trim to fit.
Height may vary depending on application.
24 3/4"
84"
3 3/4"
1 1/2"
1/4" to 3/4" Side Panels
Leading edge routed
1/4" deep, 1-1/2" top to
bottom.
1/4" to 3/4" Side Panels
Leading Edge
Flush with Cabinet
Front.
Monogram
Dimensions &
Specifications
23 9/16"
84"
2 9/16"
Trim
1/4" Side Panels
Insert end of
side panel into trim.
Standard 4" high toekick or trim to fit.
Height may vary depending on application.
Standard 4" high toekick or trim to fit.
Height may vary depending on application.
23 5/16"
84"
2 5/16"
1/2" to 3/4" Side Panels
Recessed front edge.
14
SIDE PANEL
DIMENSIONS
