Moog Grandmother Firmware Update

FUNCTIONS WITHIN THE GLOBAL EDIT MODE
This firmware version introduces a couple of useful functions which are launched from within the Global Edit system.
They are selected like other global parameters, but the functions activate immediately upon being selected, since there is
no need to set any additional parameter value for them.
V1.1.0 RELEASE NOTES
Global Parameters
Group 3
Group Select Key Parameter Select Key
3.1 Load Default Settings A#2 F#0
This function resets all the global parameters to their default values. Hold the highest black key (A#2), and while holding it
press the lowest black key (F#0). You will see the three buttons on the LHC blink rapidly for a moment to confirm that the reset
happened. Resetting the global parameters also exits Global Edit mode.
3.2 Show Firmware Version A#2 F#0
This function indicates the currently-installed firmware version, using the lights on the LHC buttons. Hold the highest black key
(A#2), and while holding it press the next-to-lowest black key (G#0). Count the number of times the PL AY, HOLD, and TAP buttons
blink on/off to read the version number. PLAY = major version number, HOLD = minor version number, TAP = minuscule/bugfix
version number. Example: this version, v1.1.0: PLAY button blinks one time, then HOLD button blinks one time, then TAP button
blinks zero times (does not light at all).

Moog Grandmother Specifications

General

Type	Analog Synthesizer
Arpeggiator	Yes
Effects	Analog Spring Reverb
Patch Points	41 Patch Points
USB	USB MIDI
Oscillators	2 x Analog Oscillators
LFO	Analog LFO
Keyboard	32-note
Sequencer	Yes
MIDI	MIDI In/Out/Thru
Audio Input	1 x 1/4"
Audio Output	1 x 1/4" (Headphone Output)
Weight	16 lbs
Power	External Power Supply
Filter	Moog Ladder Filter (Low Pass)
