Mooney M20V - Page 166

MOONEY INTERNATIONAL CORPORATION
M20V SERVICE AND MAINTENANCE MANUAL
Date
MAR 2017
Rev Date
CHAPTER 22
AUTOPILOT SYSTEMS
TABLE OF CONTENTS
CHAPTER
SECTION SUBJECT PAGE
22- 00- 00 ............................. General ............................................. 5
22- 10- 00 ................................ GFC700 AUTOPILOT Servos and Servo Mounts ..... 7
22- 10- 01 .................................... Roll Servos and Servo Mount ................... 7
22- 10- 02 .................................... Pitch Trim Serv
os and Servo Mount ............. 8
22- 10- 03 .................................... Pitch Servos and Servo Mount ................. 10
22- 10- 04 .................................... Servo Clutch Adjustment ...................... 11
22- 10- 05 .................................... Flap Discrete Input Check ..................... 13
22- 20- 00 ................................ Troubleshooting ................................. 13
22- 20- 01 .................................... LRU Replacement Procedure .................. 13
22- 20- 02 .................................... LRU Software Installation & Testing ............ 13
22- 30- 00 ................................ Autopilot Disconnect Switch ....................... 13
22- 40- 00 ................................ System Monitoring ............................... 13
22- CONTENTS
