How to splice and connect blunt ends correctly:
1. Place the strands of the wires overlapping each other
inside of the splice clip (1).
2. Using MOPAR crimping tool (1) or equivalent, crimp the
splice clip and wires together.
3. Solder (3) the connection (2) together using rosin core
solder (1).
4. Center the heat shrink tubing (2) over the solder joint and
heat using a heat gun. Heat the joint until the tubing is
tightly sealed and sealant (1) comes out of both ends of the
tubing.
