BROOKLYN 47” TV STAND | 10
Step 9
Plug in Dowel (D) into the center holes on the
side of panel (10) and (11).
Step 10
Install panel (10) and (11) onto assembled unit
by inserting camlock (B) and tightening it
with a screwdriver.
Please ensure the correct camlock placing
orientation. Check the illustration carefully.
B
x10
D
x12
Watch demo video at:
https://bit.ly/39eGJbs
Missing parts? Or feeling stuck?
Chat with us at www.mopio.com#chat
To Next Page
