12
4
2
1
4
B
B
B
BROOKLYN 47” TV STAND | 11
x2
Step 11
Slide Back Panel (12) into grooves
of assembled unit as shown.
Step 12
Install panel (1) onto assembled unit by
inserting camlock (B) and tightening it with a
screwdriver.
Please ensure the correct camlock placing
orientation. Check the illustration carefully.
Place Sticker Cam (C) over the Connecting
Cams (B).
C
x8
B
x8
Watch demo video at:
https://bit.ly/39eGJbs
Missing parts? Or feeling stuck?
Chat with us at www.mopio.com#chat
