A
x28
Cambolt
Ø 6 x 35 mm
B
Camlock
Ø 15 mm
H
M
N
C
Sticker
Ø 25 mm
I
O
Wedge
D
Dowel
Ø 6 x 30 mm
J
E
Assembly
screw
K
Screw
Ø 6 x 19 mm
x28
x24
x42
x8
x4
x4
x1
x2
x2
x12
x12
G
Hinge
x2
Screw
Ø 7 x 14 mm
Shelf Pin
Handle
80 mm
Screw
Ø 6 x 12 mm
Screw
Ø 4 x 13 mm
P
x1
Drawer runner A
Q
x1
L
x10
Screw
Ø 6 x 9 mm
F
Screw
Ø 6 x 52 mm
x12
Drawer runner B
BROOKLYN 47” TV STAND | 05
Watch installation demo video at:
https://bit.ly/39eGJbs
There are inner box(es) that include components required to
complete this assembly.
Before discarding the packaging, please use the checklist to
ensure that you have all the parts required to assemble your
product. Please kindly note you will need the original package
if you want to return the product later.
Please do not completely tighten all the hardware, until the
entire assembly is complete.
If parts are missing or damaged, we will gladly ship your
replacements parts free of charge. Please contact us at
help@mopio.com or chat with us at www.mopio.com#chat.
x1 x2 2 hours
Hardware
To Next Page
