2. TECHNICAL CHARACTERISTICS
2.a Technical Data
EUP6 EUP11
kW - kcal/h kW - kcal/h
Nominal power usage (Pn)
13,2 - 11.350
19,4 - 16.665
Nominal Thermal range (Qn)
11,6 - 9.980
21,7 - 18.662
Minimal power usage (Pm)
6,6 - 5.680
9,6 – 8.260
Minimal Thermal range (Qm)
5,8 - 4.960
10,8 – 9.288
GAS TYPE
PROPANE BUTANE PROPANE
G31 G30 G31
P.C.I. (15° C 1013 mbar) MJ/m
3
88 116,09 88
WI (15° C 1013 mbar) MJ/m
3
70,69 80,58 70,69
Consumption kg/h 1,03 1,71 1,69
Burner Pressure mbar 32,0 26,60 35,80
Nr/Ø main burner injector Nr/mm 14 x 0,5 18x0,48+6x0,50
Ø pilot ame injector mm 0,23 0,23
Ø gas connection inch 1/2” 1/2”
Flue gas load (max-min) g/s 12,48-10,29 11,80-9,75 12,48-10,29
Flue gas temperature (max-min) °C 181-115 157-110 173-118
WATER EUP6 EUP11
Input range l/min
Maximum 6 l/min Minimum 5 l/min Maximum 10.8 l/min
Water temperature lift °C approx. 25 approx. 50 approx. 25
Minimum pressure bar 0,2 0,2
Nominal pressure bar 2 2
Maximum pressure bar 10 10
Ø Water connections inch 1/2” 1/2”
Ø ue spigot diameter mm 90 110
DIMENSIONS AND WEIGHTS DEVICE PACKAGE DEVICE PACKAGE
Height mm 550 632 592 675
Length mm 255 303 314 361
Depth mm 246 283 245 280
Weight Kg 9,00 10,30 11,80 13,10
Note: relative cold water temperature of 15 °C
