AutoCreaser Pro 33A
Recommended weekly operator maintenance
l Clean all sensors
l Clean in feed rollers and output drive hubs using the cleaning kit provided
(Cleaning kit part number 90-018)
l Remove and clean the blade assembly
l With the blade assembly removed, clean the slots and surrounding area within
the creasing unit.
Technician Maintenance
It is recommended that your machine is fully serviced at least once every six months
by a factory trained Service Engineer.
Trouble Shooting
Page 46
CREASING
DISPATCH KIT
ITEM PART NUMBER QTY DESCRIPTION
1
1 OPERATORS MANUAL
-
5
90-018 1 ROLLER CLEANING KIT
8
620-004 1 ALLEN KEY 4mm
6
2
08-041-02 1 SLITTING ANVIL - UNDERSIZE.
1-99-12 1 SLITTER PERF BLADE 28T
78-007 1 MAGNETIC BACK STOP ASSY.
4
WARNING......
THE BLADES FOR ANVIL AND PERFORATING SETS ARE SUPPLIED AS
MATCHING PAIRS AND SHOULD NOT BE MIXED OR LEFT
UNPROTECTED OR SERIOUS DAMAGE MAY RESULT.
2
71-083-01
OUTRIGGER FOOT
3
7-95-30
AUTOCREASER Pro 33 (CB)70-207
12
620-028 1 BONDUS L WRENCH 3mm
11
620-026 1 BONDUS L WRENCH 4mm
2
401-02-050-008
SCREW - PAN POZI TAPTITE - M5 X 8 LONG
15
10
620-020
HEXAGON BALL DRIVER 2.5mm
1
620-007 1 HEXAGON BALL DRIVER 2mm
9
17
409-01-040-004
1 SCREW - SKT. SET FLAT PT. - M4 x 4 LG
16
403-01-030-006
12
SCREW - SOCKET CAP HEAD - M3 x 6 LG
7
617-003
5
STEEL BALL - Ø20
13
624-018 1 DISPATCH BOX
14
650-040
1 POWER
CORD CE
UK C19 3Pin 16A 2.5Mtrs.
