Page16
HANDFEDCREASING
Allofthebladesandanvilsaresuppliedwithfixings.
*Perforatorstripper StandardPartNumber 78-013
*Itisrecommendedthatformultipleperforations,aseparateperforatorstripperisusedfor
everyperforatingbladesetfittedinthecreasingunit.
Settingthemachine
1. Turnthemainssupplytothemachine‘off’.
2. Removethestackerunitandopentheexitguard.
3. Locateandremovetheblades/anvilsfromthedespatchkitsuppliedwiththe
machine.
4. Usingthe2mmallenkey(supplied),loosenthedrivewheelthatistoaccommodate
theblades.
5. Slidethedrivewheelawayfromanyobstructingdrivewheelsorhubsinorderto
mounttheblades.
6. Usingthe2.5mmallenkey(supplied),takeone
ofthematchingpairsandmountontothedrive
wheel.Donotsecuretheblade.
7. Mounttheothermatchingpairtothedrivewheel
asshown(fig16.1).Securethebladestothe
wheelensuringnottoovertightengrubscrew.
8. Markonasinglesheetthedesiredperforating
position.Feedthesheetthroughthemachine
manuallyuntilthemarkcanbeseen.Usethis
marktoassistinfixingthepositionofthe
perforatingdrivewheeltotherollerdriveshaft.
9. Usingthe2mmallenkey,loosenthedrivehub
nearesttheperforatingdrive.Slidethedrivehub
awayfromanyobstructingdrivewheelsorhubs
inordertomounttheanvils.
10. Usingthe2,5mmallenkey,takeoneofthe
matchingpairsofanvilsandmounttothedrive
hub.Donotsecuretheanvil.
FIG16.2
FIG16.1
Perforating
