Morgana DigiCreaser - Replacing the Creasing Blade Set

Page20
HANDFEDCREASING
1. Beforeremovingthebladeassembly,ensurethatthelowerblade/anvilisNOT
at‘topdeadcentre’,Switchthemachineoff.
2. Removethestackerunitandlifttheexitguard.
BladeExtractorTools3.
Usinga6mmallenkey,loosenthesocket
headscrewslocatedinsidetheblade
adjustmentcams.Removethescrewsand
thebladeadjustmentcams.
4.
Insertthebladeextractortools(70-055-01&
70-055-02)intotheholesintheadjustment
links,asshown.Pushdownwardsonthe
handlesofthebladeextractortoolsto
releasethebladeassemblyfromthepower
links.
5.
Slidethebladeassemblyoutofthecreasing
unitandlayitonaflatsurface.
6.
Slidetheadjustmentlinksawayfromthe
dowelslocatedintheendsoftheblades/
anvilsasshowninthephotograph(left)
7.
Placethenewbladesetintoposition.
Checkthattheeccentricshoulderboltson
thelinkplateshavebeenpositionedas
showninfig20.1.
8.
(Upperblade/anvilonly)
Slidetheadjustmentlinksontothedowels.
9.Slidethenewbladesetintotheslotsofthe
creasingunitasshowninfig.21.1.
Locatethebladeextractortoolsintotheholesin
theadjustmentlinksasshown.Pullthehandles
ofthebladeextractortoolsupwardstoengage
thebladeassemblybackintothepowerlinks.
10. Setthecamgraphicsforbothendsoftheblade/
anviltotheirlowestpointonthescale(ie.When
themarkonthescalereachesthemarkoncam
holder)Fastenthesocketheadscrewsonthe
adjustmentcamsuntiltheyaretight.
FIG20.1
ReplacingBladeSet
