Morgana Documaster Pro - Page 37

Page35SYSTEM
FIGURE38
OrangeHandScrews
FIGURE39
Blade
Anvil
MarkAlong
Here
Procedure
SeparatetheTMPfromtheBMP.OpentheTMPconveyor
cover(loosentheorangehandnut).Removethetwo
orangehandscrewsthatsecuretheconveyorassembly
totheTMPunit(seeFigure38).
Liftawaytheconveyorassemblytorevealtheblade
assembly(seeFigure39).
Important
NotetheangledpositionoftheTMPbladeandwitha
markerpenorsimilar,markalongthebottomedgeof
theblade(seeFigure39).Thiswillactasaguidewhen
refitting.
DocuMasterPro
