B-26 REGULAR INSPECTION
5) Remove the screws of the battery holder.
6) Remove the connector attached to the battery.
Do not pull the battery cable.
7) Pull the battery out.
8) Fit a new battery.
14.1.3 Type 2 (Operation Panel Side)
Change the battery with the power supply shut off.
Be sure to change the battery in less than 30 minutes.
The data stored in the memory will be lost if the power supply is shut off for 30 minutes
or more.
To avoid the danger of lost data, you are recommended to save the memory data to an
external I/O device.
Mori Seiki does not have any responsibility for the loss of memory data.
<Battery position>
The battery unit is installed inside the operation panel.
<Changing interval>
Every 10 years
When a battery symbol is displayed on the screen.
NOTE
CAUTION
Operation panel
Holder
Screw A
To Next Page
