SPECIFICATIONS
BC430 BC430E (EU V)
Power transmission Automatic centrifugal clutch, spiral bevel gear, flexible drive shaft
Max speed of gear shaft/engine speed (r/min) 7000/9000
Idle Speed (r/min) 2800 +/-150 2800 +/-280
Vibration value at each handle <7.5m/s
2
<6.9m/s
2
Sound pressure level (in accordance with EN ISO11806:1997,
EN27917:1987)
<105(db(A)) <90(db(A))
Sound power level (in accordance with ISO 10884) <120(db(A)) <111(db(A))
Reduction ratio 16:19 17:22
Blade rotation direction Counter clockwise (seen from top)
Handle type “U” Type
Weight (dry) 7.4 7.7
Engine model No HB40 1E40F-2E
Certification HB43: : CN FD G1 EU V
Type Air cooled, 2 cycle, vertical, piston valve, petrol engine
Displacement (ml) 42.7 42.7
Maximum output (kW/r/min) 1.25/6500 1.1kW/7500
Carburetter Diaphragm type
Ignition Non contact electronic ignition
Starting method Recoil type
Fuel used Petrol mixed with lubricating oil (25:1)
Fuel tank capacity (l) 1.1
Dry weight 3.8 4.2
Length of main shaft (mm) 1500
Length of inner drive shaft (mm) 1522
Standard Blade (mm) 3 Tooth blade (255x1.4)
