Morso 1410 Squirrel - 1.0 Installation of your Morsø stove; 1.1 Unpacking the stove

4
DK ENG
Installation of woodburning stoves must be safe and legal.
If your Morsø stove is not installed correctly, it may cause a house re. To reduce the risk
of re, the installation instructions must be followed carefully. Contact the local building
ocials about restrictions and installation inspection in your area.
Before you start installing your stove, make sure that:
- The stove and chimney connection are placed far enough from combustible materials to
meet all clearance requirements.
- The oor protection must be adequate and must be made correctly according to the re-
quirements.
All neccessary approvals are needed from the local building ocials.
The data plate, which is located on the back of the stove, provides information regarding safety
testing information, name of certied testing laboratory, and installation requirements.
Installation requirements vary in dierent districts, and the local building ocials have the nal
authorization to approve your installation. You should discuss the installation with them before
beginning. Please ask your dealer for further information.
Do not connect to any air distribution duct or system.
Important: If the installation instructions are not
followed carefully, it may cause dangerous situa-
tions like chimney - and house res. Follow the in-
structions carefully and do not deviate from them
as it may cause injuries to people or property.
1.1 Unpacking the stove
After removing the outer packaging, atten it and lay
onto the oor close to the stove; this can then act as
protective work surface during the assembly process.
Next, remove the legs from inside the stove. Carefully
lift the stove from the wooden pallet and gently lay the
stove onto its back and unscrew the heat shield from
the underside of the stove. Now screw the legs and
the Heat shield into position on the underside of the
base. Following the removal of the wooden packaging
the heat shield must be tted to the underside of the
stove at the same time as the legs utilising the same
xing bolts. Please see drawing. The stove should now
be lifted and moved into the upright position, avoiding
excess load on the back legs.
We recommend that two people perform the as-
sembly and installation procedure. The Morsø 1410
weighs 75 kg.
