Morso 1410 Squirrel - Page 9

9
In the US, oor protection must be constructed of a non-combustible material and installed
to extend beneath the heater and 16’’ to the front and 8’’ to the sides of the fuel loading
door and ash removal openings. In Canada, oor protection must be constructed of a non-
combustible material and installed to extend beneath the heater and 450 mm.(16’’) to any
side with a door and 200 mm.(8’’) beyond the appliance on the other sides.
CLEARANCE REQUIREMENTS ALCOVE INSTALLATION
USA CANADA
W. Minimum alcove width
D. Maximum alcove depth
G. Alcove ceiling above stove top
56”
24”
36”
1420 mm
610 mm
915 mm
FLOOR PROTECTION REQUIREMENTS NONCOMBUSTIBLE MATERIALS
BENEATH STOVE
USA CANADA
A. Extending distance, back
B. Extending distance, right side
C. Extending distance, left side
D. Extending distance, front
-
6”
6”
16”
200 mm
200 mm
200 mm
450 mm
