Morton
®
Water Softener Installation & Operation Manual 25
Valve Parts List
Key
No.
Part No. Description
– 7373810
Motor, Cam & Gear Kit, 3/4”
(includes Key Nos. 50-52)
50
á
Motor
51
á
Cam & Gear
52 7338111 Screw, #6-19 x 1-3/8” (2 req.)
53 7337474 Motor Mount
54 7030713 Switch
– 7331185
Drain Hose Adaptor Kit
(includes Key Nos. 55-59)
55
á
Clip, Drain
56
á
Drain Hose Adaptor
57
á
Hose Clamp
58
á
O-Ring, 5/8” x 13/16”
59
á
Flow Plug, 2.0 gpm
– 7129716 Seal Kit (includes Key Nos. 60-65)
60
á
O-Ring, 7/16” x 5/8”
61
á
O-Ring, 3/4” x 15/16”
62
á
O-Ring, 3-3/8” x 3-5/8”
63
á
Rotor Seal
64
á
O-Ring, 3/8” x 9/16”
65
á
Seal, Nozzle & Venturi
66 7082087 Wave Washer
67 7199232 Rotor & Disc
– 7342665
Drain Plug Kit, 3/4”
(includes Key Nos. 64, 68 & 69)
68
á
Plug, Drain Seal
69
á
Spring
Key
No.
Part No. Description
70 7337563 Clip, 3/4”, pack of 4
71 7370286
Bypass Valve Assembly, 3/4”, in -
cluding 2 O-Rings (See Key No. 72)
72 7337571 O-Ring, 15/16” x 1-3/16”, pack of 4
– 7113040
Turbine & Support Assembly,
including 2 O-Rings (See Key No.
72) & 1 ea. of Key Nos. 73 & 74
73
á
Turbine Support & Shaft
74
á
Turbine
75 7082053 Valve Body
76 7081201 Retainer, Nozzle & Venturi
77 7342649 O-Ring, 1/4” x 3/8”, pack of 2
78 1202600 Nut - Ferrule
– 7257454
Nozzle & Venturi Assembly
(includes Key Nos. 76, 77 & 79-87)
79 7081104 Housing, Nozzle & Venturi
80 7095030 Cone Screen
81 1148800 Flow Plug, .3 gpm
82
7114533 Nozzle & Venturi Gasket Kit
7204362 Gasket Only
83 7084607 Flow Plug, .15 gpm
84 7146043 Screen
85 7167659 Screen Support
86 7170262 O-Ring, 1-1/8” x 1-3/8”
87 7199729 Cap
88 7309803 Wire Harness, Sensor
89 7337466 Valve Cover
90 7342657 Screw, #10-14 x 2”, pack of 5
