Mortonr Water Softener Installation & Operation Manual
25
REPAIR PARTS
KEY
NO.
PART
NO.
DESCRIPTION
-- 7331177
Tank Neck Clamp Kit
(includes 2 ea. of Key Nos. 1 & 2)
1 Clamp Section (2 req.)
2 Retainer Clip (2 req.)
-- 7112963
Distributor O--ring Kit
(includes Key Nos. 3--5)
3 O--ring, 2--7/8 in. x 3--1/4 in.
4 O--ring, 13/16 in. x 1--1/16 in.
5 O--ring, 2--3/4 in. x 3 in.
6 7077870 Top Distributor
7 7105047 Repl. Bottom Distributor
8 0502272 Resin, 53 lbs (1 cu ft)
9 7247996 Resin Tank, 10 in. dia x 40 in.
10 7265025 Filter Screen
11 7189449 Bottom Cover
12 7174868 Faceplate Cover (order decal below)
z
7310901 Decal, Faceplate
13 7310969 Repl. Electronic Control Board (PWA)
KEY
NO.
PART
NO.
DESCRIPTION
14 7351054 Power Supply, 24V DC
15 7192785 Salt Cover
16 7178626 Rim
17 7155115 Cover, Brinewell
18 7109871 Brinewell
-- 7331648
Brinewell Mounting Hardware Kit
(includes Key Nos. 19 & 20)
19 Wing Nut, 1/4--20
20 Screw, 1/4--20 x 5/8 in.
21 7161831
Repl. Brine Tank
(includes Key Nos. 18--20)
-- 7331258
Overflow Hose Adaptor Kit
(includes Key Nos. 22--24)
22 Adaptor Elbow
23 Grommet
24 Hose Clamp
25 7310202 Brine Valve Assembly
26 7327568 Float, Stem & Guide Assembly
z
7139999 Drain Hose, 20 ft.
z not illustrated.
Questions? Call To ll Free 1--888--64 WAT ER (1--888--649--2837)
or visit www.mortonwatersofteners.com
When you call, please be prepared to provide the model and serial number,
located on the rating decal on back of the top cover .
