REPAIR PARTS
KEY
NO.
PART
NO.
DESCRIPTION
50 7224087 Screw, #8-32 x 1 in. (2 req.)
51 7286039 Motor (incl. 2 ea. of Key No. 50)
52 7231393 Motor Plate
53 0900857 Screw, #6-20 x 3/8 in. (3 req.)
54 7171250 Bearing
55 7283489 Cam and Gear
-- 7331169
Drain Hose Adaptor Kit
(includes Key Nos. 56--60)
56 Clip (Drain)
57 Hose Clamp
58 Drain Hose Adaptor
59 O-ring, 15/16 in. x 1--3/16 in.
60 Flow Plug, 2.0 gpm
-- 7185487 Seal Kit (includes Key Nos. 61--66)
61 O-ring, 5/8 in. x 13/16 in.
62 O-ring, 1--1/8 in. x 1--1/2 in.
63 O-ring, 4--1/2 in. x 4--7/8 in.
64 Rotor Seal
65 Seal
66 Seal (Nozzle & Venturi)
67 7174313 Bearing, Wave Washer
68 7185500 Rotor & Disc
-- 7342665
Drain Plug K it, 1 in.
(includes Key Nos. 65, 69 & 70)
69 Plug (Drain Seal)
70 Spring
71 7337589 Clip, 1 in., pack of 4
72 7342704
Installation Adaptor, 1 in., pack of 2,
including 2 ea. Clips & O--Rings
(See Key Nos. 71 & 73)
73 7337597
O--Ring, 1--1/16 in. x 1--5/16 in.,
pack of 4
KEY
NO.
PART
NO.
DESCRIPTION
-- 7290931
T urbine & Support Assembly,
including 2 O--Rings (See Key No.
73) & 1 ea. of Key Nos. 74 & 75
74 T urbine Support & Shaft
75 Turbine
76 7309811 Sensor Housing/Wiring Harness Asm.
77 7081201 Retainer (Nozzle & Venturi)
78 7171145 Valve Body
79 7342649 O-ring,1/4in.x3/8in.,packof2
80 1202600 Nut — Ferrule
-- 7257454
Nozzle & Venturi Assembly
(includes Key Nos. 77, 29 & 81--89)
81 7081104 Housing, Nozzle & Venturi
82 7095030 Cone Screen
83 1148800 Flow Plug, .3 gpm
84
7114533 Nozzle and Venturi — Gasket Kit
7204362 Gasket (only)
85 7084607 Flow Plug, .15 gpm
86 7146043 Screen
87 7167659 Screen Support
88 7170262 O-ring, 1--1/8 in. x 1-3/8 in.
89 7199729 Cap
90 7175199 Wave Washer
91 7171161 Valve Cover
92 7342681 Screw, #10 x 2--5/8 in., pack of 8
93 7305150 Switch
94 7140738 Screw, #4-24 x 3/4 in. (2 req.)
95 7214383
Bypass Valve Assembly, 1 in.,
including 2 ea. Clips & O--Rings
(See Key Nos. 71 & 73)
Questions? Call To ll Free 1--888--64 WAT ER (1--888--649--2837)
or visit www.mortonwatersofteners.com
When you call, please be prepared to provide the model and serial number,
located on the rating decal on back of the top cover .
