Engine starting MAGIC WELD
M
26
© MOSA 1.0-05/04
21/05/04 22243-GB
check daily
Do not alter the primary conditions of
regulation and do not touch the sealed parts.
NOTE
!
1. Turn the fuel cock (87) to ON.
RUBINETTO COMBUSTIBILE
2. Switch the choke control (66) to CLOSE
N.B.: Do not use the air valve if the motor is
hot or the air temperature is too high.
CHOKE LEVER
CLOSE
CLOSE
3.Turn the engine switch (28) to the ON position
ENGINE SWITCH
STARTER GRIP
Lightly pull the start-up knob (73) until meeting
resistance, then pull decisively.
ATTENTION:
Allow the start-up knob to re-enter slowly,
avoiding having it knock against the motor and
thereby damaging the start-up system.
4.When the engine is started the machine
reaches maximum engine speed immediately
(4000 rpm) for 6/7 seconds, after which the
engine speed automatically decreases to
minimum (2000 rpm). The minimum is set by
the solenoid which acts on the accelerator
lever.
5.The engine reaches maximum speed only
when current is drawn in welding or auxiliary
power mode.
