22 Configuration
Connections
Configuring Inputs
• On the Connections menu, click Devices
• Select the device (e.g. C185) and then click the Input pins tab
This will list all inputs available for this product
Note: Some inputs require the 52 I/O Upgrade to make them available.
See C185 Upgrades
• Select the input and click Channel (or double click the input)
• Assign a measurement channel to the input and click OK
The channel needs to be calibrated using one of two options
• Select Load Cal if a pre-defined calibration is available
OR
• Double-click the input to enter a calibration
Other tasks:
• Change Cal – to change the calibration
• Spd Levels – only for speed inputs
• Settings – to set default
Configuring Outputs
• On the Connections menu, click Devices
• Select device (e.g. C185) and then click the Output Pins tab to list all
outputs available for this product
Note: Some outputs require 52 I/O Upgrade to make them available. See
C185 Upgrades.
• Select the output and click Change (or doubleclick the output)
• Select a mode to make appropriate settings available
• Follow the directions on the screen and when all settings are done click
OK
Configuring Communications
• On the Connections menu, click Communications
• Select an available communications section (CAN or RS232)
• Click Select and choose one of the available communications templates
