MoTeC Appendices 49
Pin List by Pin Number
Pin Name Function
1 AV15 Analogue Voltage Input 15
2 AV16 Analogue Voltage Input 16
3 AV17 Analogue Voltage Input 17
4 AV18 Analogue Voltage Input 18
5 AV19 Analogue Voltage Input 19
6 0V Sensor 0 V
7 BAT- Battery Negative
8 BAT+ Battery Positive
9 AUX1 Auxiliary Output 1
10 AUX2 Auxiliary Output 2
11 AUX3 Auxiliary Output 3
12 AUX4 Auxiliary Output 4
13 AUX5 Auxiliary Output 5
14 AUX6 Auxiliary Output 6
15 RS232-2 TX RS232-2 Transmit Output
16 RS232-2 RX RS232-2 Receive Input
17 0V Sensor 0 V
18 5V Sensor 5 V
19 AV7 Analogue Voltage Input 7
20 AV8 Analogue Voltage Input 8
21 AV9 Analogue Voltage Input 9
22 AV10 Analogue Voltage Input 10
23 AV11 Analogue Voltage Input 11
24 AV12 Analogue Voltage Input 12
25 AV13 Analogue Voltage Input 13
