50 Appendices
Pin Name Function
26 AV14 Analogue Voltage Input 14
27 0V Sensor 0 V
28 5V Sensor 5 V
29 Reserved
30 Reserved
31 Reserved
32 Reserved
33 0V Sensor 0 V
34 AT1 Analogue Temp Input 1
35 AT2 Analogue Temp Input 2
36 AT3 Analogue Temp Input 3
37 AT4 Analogue Temp Input 4
38 AT5 Analogue Temp Input 5
39 AT6 Analogue Temp Input 6
40 0V Sensor 0 V
41 AT7 Analogue Temp Input 7
42 AT8 Analogue Temp Input 8
43 0V Sensor 0 V
44 5V Sensor 5 V
45 AV1 Analogue Voltage Input 1
46 AV2 Analogue Voltage Input 2
47 AV3 Analogue Voltage Input 3
48 AV4 Analogue Voltage Input 4
49 AV5 Analogue Voltage Input 5
50 AV6 Analogue Voltage Input 6
51 0V Sensor 0 V
52 DIG1 Digital Input 1
