MoTeC Appendices 51
Pin Name Function
53 DIG2 Digital Input 2
54 DIG3 Digital Input 3
55 DIG4 Digital Input 4
56 0V Sensor 0 V
57 SW1 Switch Input 1
58 SW2 Switch Input 2
59 CAN4L CAN 4 Low
60 CAN4H CAN 4 High
61 0V Sensor 0 V
62 8V Sensor 8 V
63 SPD1 Speed Input 1
64 SPD2 Speed Input 2
65 SPD3 Speed Input 3
66 SPD4 Speed Input 4
67 E-TX+ Ethernet Transmit +
68
E-TX– Ethernet Transmit –
69 AV20 Analogue Voltage Input 20
70 RS232-1 TX RS232 Transmit Output
71 CAN3L CAN 3 Low
72 CAN3H CAN 3 High
73 CAN1L CAN 1 Low
74 CAN1H CAN 1 High
75 CAN2L CAN 2 Low / RS232 Ground Input
76 CAN2H CAN 2 High / RS232 Receive Input
77 E-RX+ Ethernet Receive +
78
E-RX– Ethernet Receive –
79 RS232-1 RX RS232 Receive Input
