Step 8: Measure the DC current from –output terminals ( - and COM) with the DMM and keyin the
measured value (i.e. if the DMM shows 0.642A then keyin 0.642) followed by the “ENTER”
key.
The following message will then appear on the LCD:
Step 9: Repeat step 8. Keyin the measured value (i.e. if the DMM shows 2.418A, then keyin 2.418)
followed by the “ENTER” key. The following message will then appear on the LCD：
ADC GET=00200
CV
CV
INDEP
5V
-I Lo=0.624
CC
CC
TRACK
3.3V
ADC GET=02503
CV
CV
INDEP
5V
-I Hi=2.418
CC
CC
TRACK
3.3V
MOTECH LPS 305
CV
CV
INDEP
5V
Version 1.17
CC
CC
TRACK
3.3V
ALL OUTPUT OFF
CV
CV
INDEP
5V
10.00V -10.00V
CC
CC
TRACK
3.3V
