1.3 Options
Options 01 determine which line voltage is set at the factory. This information is on the rear panel
label.
Option 01: RS-232 Interface
Option 02: Rack mount Shelf
1.4 Accessories
Power cable
Operation manual
Fuse
1.5 Output Isolation
The output of the power supply is isolated from earth ground. Either output terminal may be grounded
or the output may floated up to +/- 240 Vdc (including output voltage) from chassis ground
1.6 Specifications
TRIPLE OUTPUT LINEAR POWER SUPPLY UP TO 165 WATTS
Model
LPS 305
MAX. OUTPUT POWER
165 WATTS
OUTPUT VOLTAGE
Output Voltage
0 to +30V / 0 to -30V
Fixed 3.3V / 5V
Setting Resolution
10mV
Max. output voltage
+32V / -32V
Dual tracking
0 to 30V
Tracking deviation
20mV
OUTPUT CURRENT
Output Current
0 to +2.5A / 0 to -2.5A
3A
Setting Resolution
1mA
Max. output current
+3A / -3A
Current limited approx. 3.3A
Dual tracking
0 to 2.5A
Tracking deviation
5mA
CONSTANT VOLTAGE CHARACTERISTICS (at rated output : 2.5A )
Line regulation(for change of AC 10%)
1mV
5mV
Load regulation(for load change 0 100%)
2mV
10mV
Ripple/Noise rms
1.5mVrms
2mVrms
