4
Ripple/Noise (p-p)
10mVp-p
20mVp-p
Transient Response
200s Typical
Temperature Coefficient
100ppm / ℃ Typical
CONSTANT CURRENT CHARACTERISTICS (at rated output : 2.5A )
Line regulation (for change of AC 10% )
15mA Typical
Load regulation (for change from short to
full load )
10mA Typical
Ripple/Noise rms
1mArms Typical
Ripple/Noise (p-p)
5mAp-p Typical
Temperature Coefficient
200 ppm / ℃ Typical
Display
2×16 LCD with backlit; Front Panel Status
Announciators with beeper
Voltage Accuracy*
( 0.2% of rdg +2 digits )
Current Accuracy*
( 0.5% of rdg +5 digits )
Common Mode Voltage
±240Vdc
Temperature ranges
Operating: 0℃ to 40℃, less than 80% RH;
Storage: -40℃ to 70℃, less than 80% RH
Dimensions (W × H × L)
8.4" × 5.2" × 15.7"
Weight
Approx. 18 lbs
Cooling
Fan Cooled
Power Source
AC 115V  10% OR 230V  10%, 47 to 63Hz
Current Consumption
2.88A / AC 115V or 1.48A / AC 230V
Fuse Rating
5AT / 250V for AC 115V, 2.5AT / 250V for AC 230V
Options
RS-232
Accessories
User’s manual, power cord, fuse
*For output less than 5% of rated output, add 5 digits to the accuracy specification
RS232 Interface capabilities:
1. RS232C DCE interface: 9-pin D-SUB connector.
2. Port configuration: asynchronous 2400 baud, 8 data bits, 1 stop bits, no parity.
