If you ignore these Warnings or fail to inspect or maintain your
wheelchair as directed in the manual , you may fall, tip over or lose
control of the wheelchair and seriously injure yourself or others or
damage the wheelchair.
Static stability Test results - Helio C2
Reference Stability Direction Tipping angle
Least stable Most stable
9,0 Forward Front wheels locked 9,3 9,5
N/A ° N/A °
Front wheels unlocked 9,2 9,4
32,0 ° 36,8
10,0 Rear Rear wheels locked 10,3 10,5
7,4 ° 8,8 °
Rear wheels unlocked 10,2 10,4
7,9 ° 15,3 °
11,0 Rear Antitip devices 11,2 11,3
11,1 ° 12,2 °
12,0 Sideways 12,1 12,2
Left 21,0 ° 24,0 °
Right 21,0 ° 24,0 °
The ISO7176 tests are available for the Motion Composites wheelchair user, service center, retailor or distributor.
Please contact our service department at info@motioncomposites.com or call 1-450-588-6555 to get the complete test results.
Disclosure Information (ISO) chart
Standard reference min. max. Standard reference min. max.
Overall length with legrest 711,2 1130,3 ISO7176-7 7.3.2 Seat plane angle 0° 25.0°
Overall width 546,1 749,3 ISO7176-7 7.3.3 Effective seat depth 355,6 508
Folded length 711,2 1130,3 ISO7176-7 7.3.5 Eff ective seat width 355,6 558,8
Folded width 317,5 419,1 ISO7176-7 7.3.6 Seat surface height at front edge 330,2 539,8
Folded height 609,6 1092,2 ISO7176-7 7.3.7 Backrest angle -5.0° 20.0°
Total mass 7.5kg 15.5kg ISO7176-7 7.3.8 Backrest height 381 533,4
Mass of the heaviest part 12kg 7.8kg ISO7176-7 7.3.12 Footrest to seat distance 342,9 533,4
ISO7176-1 Clause 9 Static stability downhill (UNLOCK) 20.7° 31.8° ISO7176-7 7.3.16 Leg to seat surface angle 90.0° 60.0°
ISO7176-1 Clause 10 Static stability uphill (UNLOCK) 7.4° 8.8° ISO7176-7 7.3.17 Armrest to seat distance 203,2 355,6
ISO7176-1 Clause 11 Static stability sideways 21.0° 24.0° ISO7176-7 7.3.18 Front location of armrest structure 254 355,6
Energy consumption N/A N/A ISO7176-7 7.3.24 Handrim diameter 431,8 590,6
Dynamic stability uphill N/A N/A ISO7176-7 7.3.26 Horizontal location of axle 19,1 88,9
Obstacle climbing N/A N/A ISO7176-5 3.25 Minimum turning radius 990,6 -
Maximum speed forward N/A N/A ISO7176-3 9a Parking brake - Maximum slope downhill 12,1 -
Min. braking distance - max speed N/A N/A ISO7176-3 9a Parking brake - Maximum slope uphill 12,2 -
Conversion chart
Inches Metric Inches Metric Inches Metric Inches Metric
1/4” 0.6 cm 1” 2.5 cm 10” 25.4 cm 19” 48.3 cm
1/2” 1.3 cm 2” 5.1 cm 11” 27.9 cm 20” 50.8 cm
3/4” 2.0 cm 3” 7.6 cm 12” 30.5 cm 21” 53.3 cm
4” 10.2 cm 13” 33.0 cm 22” 55.9 cm
5” 12.7 cm 14” 35.6 cm 23” 58.4 cm
6” 15.2 cm 15” 38.1 cm 24” 61.0 cm
7” 17.8 cm 16” 40.6 cm 25” 63.5 cm
8” 20.3 cm 17” 43.2 cm 26” 66.0 cm
9” 22.9 cm 18” 45.7 cm
