model no. 011-1981-2 | contact us 1-888-942-6686
CONNECTING YOUR BATTERY
BATTERY REMOVED FROM VEHICLE
1. Before connecting and disconnecting the DC
output clamps, remove the AC plug from the
electrical outlet.
2. Connect the positive (red) charger clip to the
positive (POS, P, +) post of battery.
3. Attach at least a 60 cm (24˝) long 6-gauge
(AWG) insulated battery cable to a negative
(NEG, N, -) battery post.
4. Position yourself and the free end of cable
as far away from battery as possible, then
connect the negative (black) charger clip to
the free end of cable. DO NOT face battery
when making final connection.
5. Connect charger AC supply cord to electric
outlet. (Reverse process to remove charger.)
6. When disconnecting chargers, ALWAYS do so
in reverse sequence of connecting procedure
and break first connection while standing as
far away from battery as practical.
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
NOTE:
NEVER allow the DC output clamps to touch each other. This may cause a spark.
Check polarity of battery posts. A positive (POS, P, +) battery post usually has a larger
diameter than a negative (NEG, N,-) battery post.
WARNING!
A spark near a battery may cause a battery explosion!
NOTE: a marine battery installed in a boat must be removed and
charged on shore. To charge it onboard requires equipment specially
designed for marine use.
