EN
30
MESSAGES MEANING
--
Gate closed or switch-on after shutdown
OP
Gate opening
CL
Gate closing
SO
Gate stopped during opening
SC
Gate stopped during closure
F1
Photocell 1 tripped
F2
Photocell 2 tripped
HA
Gate stopped by external event
ALI
Re-alignment procedure
oP
Gate stopped without automatic reclosure
OPd
Gate in parcial opening mode
Pe
Gate in parcial opening position without automatic reclosure
-tC
Gate open with timed reclosure
Flashing dash counting in progress
Dash replaced by gures 0..9 countdown (last 10s)
-tP
Gate in parcial opening position with timed reclosure
Flashing dash counting in progress
Dash replaced by gures 0..9 countdown (last 10s)
L--
Learning started on limit switch (move the gate o the limit switch to continue the learning procedure) or learning
stopped due to trip of safety device or motor inversion.
LOP
Learning opening
LCL
Learning closure
4.7 - Display during normal operation
In “NORMAL OPERATING MODE”, i.e. when the system is powered up normally, the 3-gure LCD display shows the following status messages:
In addition, the dots between the gures illustrate the status of the limit switches, as described in greater detail below:
MESSAGES MEANING
-.-
Limit switch CLOSED (one dot between the two lines)
tC.
Limit switch OPEN (a point to the right)
SO
No limit switch active (no dots present)
EVENT DESCRIPTION
BUTTON TO MAIN CONTROL FLASHING
LIGHT AND LEDS CONTROL UNIT
opening Gate opening
closure Gate closing
automatic closure Gate open with timed reclosure active
stop during closure Gate stopped during closure
stop during opening Gate stopped during opening
open
Gate completely open without automatic reclo-
sure
closed Gate completely closed
programmation During the programming phase 2 quick ashes + pause + 1 ash
obstacle M1 Motor 1 obstacle detected 4 quick ashes + pause, 3 times
photo 1! Photocell 1 tripped 2 quick ashes + pause, 3 times
photo 2! Photocell 2 tripped 2 quick ashes + pause, 3 times
sensitive edge! Sensitive edge tripped 5 quick ashes + pause, 3 times
parcial opening Parcial opening in progress
automatic parcial closure
Gate opening to parcial position with timed reclo-
sure activated
realignment Realignment after a manual release
phototest error Phototest error detected 3 quick ashes + pause, 3 times
