14 AP-0622 Access Point
10. Verify the access point is receiving power by observing that the LEDs are lit or flashing.
2.6.3 Wall Mount Procedure - Existing Access Point Replacement
An existing external antenna model AP300 (WSAP-5100-100) or external antenna model AP650 (AP-0650-660X0)
access point, installed on a wall (plenum installation), can be placed by an AP-0622. Simply remove the existing
legacy model access point form its mounting screws, leave the mounting hardware in place and install the new
external antenna model AP-0622 directly on to the existing mounting hardware. The cabling procedure for such a
replacement is as described in the previous section.
CAUTION If not using a 802.3af capable controller to power the AP622, ensure
only the AP622’s designated power supply (PWRS-14000-148R) is
used to supply power to the access point. Using an incorrectly rated
power supply could damage the unit and void the product warranty.
Do not actually connect to the power source until the cabling portion
of the installation is complete.
