Installation Guide 7
2 Hardware Installation
2.1 Installation Instructions
The AP-0622 access point mounts either on a wall (with customer supplied M4 x 25 pan head screws and wall
anchor - or equivalent) or on a suspended ceiling T-bar. If deploying an external antenna model AP622, access point
mounting kit (Part No. KT-135628-01) is required. An AP-0622 is not designed for mounting on a desk.
To prepare for the installation:
1. Match the model number on the purchase order with the model numbers in the packing list and on the case of
the access point.
2. Verify the contents of the box include the intended AP-0622 access point, and he included hardware matches
the package contents on page 4.
3. Review site survey and network analysis reports to determine the location and mounting position for the
AP-0622 access point.
4. Connect a CAT-5 or better Ethernet cable to a compatible 802.3af power source and run the cable to the
installation site. Ensure there is sufficient slack on the cable to perform the installation steps.
2.2 Precautions
Before installing an AP-0622 model Access Point, verify the following:
• Your using the correctly rated power supply for the AP-0622 (PWRS-14000-148R)
• Motorola Solutions recommends you do not to install the AP-0622 in wet or dusty areas.
• Verify the environment has a continuous temperature range between 0° C to 40° C.
Part Number Description
AP-0622-66030-US 802.11n dependent access point, dual radio, internal antenna
AP-0622-66040-US 802.11n dependent access point, dual radio, external antenna
AP-0622-66030-WR 802.11n dependent access point, dual radio, internal antenna
AP-0622-66040-WR 802.11n dependent access point, dual radio, external antenna
NOTE
In the above part numbers, a country code of “WR” represents a world
wide model, whereas “US” defines the model as only legally deployable
in the United States.
NOTE When operating in a Gigabit Ethernet environment, CAT-5e or CAT-6 cable
is recommended for Gigabit operation.
