1.5 AP-7522 Antennas
An AP-7522 external antenna Access Point supports the following dual band antenna options:
An AP-7522 internal antenna Access Point supports the following dual band antenna:
Part Number Antenna Type 2.4 GHZ Gain (dBi) 5 GHZ Gain (dBi) Impdance (Ohms)
ML-2452-APA2-01 Dipole 3.17 4.6 50
ML-2452-HPA5-036 Dipole 3 5 50
ML-2452-APAG2A1-01 Dipole 2.7 1.7 50
ML-2452-PNA5-01R Panel 5.5 6 50
Part Number Antenna Type 2.4 GHZ Gain (dBi) 5 GHZ Gain (dBi) Impedance (Ohms)
BIRCH-INT-ANT Monopole 4.13 5.92 N/A
